Solar Lawn Lights Mini Epoxy Resin Solar Panel With High Conversion Rate

Yuyao Ollin Photovoltaic Technology Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

Solar Lawn Lights Mini Epoxy Resin Solar Panel With High Conversion Rate

Brand Name : OLLIN PV

Model Number : OEM

Certification : CE

Place of Origin : zhejiang Pr. China

MOQ : 1 piece/unit

Price : negotiation

Supply Ability : 230000PCS PER WEEK

Delivery Time : 20DAYS

Packaging Details : carton,

Material : polycrystalline silicon

Color : dark blue

dimension : OEM

Frame : no frame

Epoxy : solar panels

Shape : round

Contact Now

Epoxy Resin Solar Panel board DIY solar lawn lights small solar water pumps solar radio solar flashlight


Product Features:


High conversion rate, high efficiency output


Excellent low-light effect


Epoxy resin with high transmittance quality, hardness is 80, the surface scratches can not be avoided, but


does not affect the workingUnique technology makes assembly solid and beauty can anti-snow, easy to


install


Unique technology to avoid water freezing and deformation

Item No.Max PowerRated VoltageOutput VoltageDimensionNet Weight
0.5V100MA0.05W0.5VDC53x18x3mm0.003kg
1V85MA0.085W1VDC30x25x3mm0.0022kg
1.5V400MA0.65W1.5VDCCharge for 1.2V Battery80x60x3mm0.018kg
2V130MA0.26W2VDC54x54x3mm0.009kg
2V50MA0.1W50x34x3mm0.008kg
3V120MA0.36W3VDC60x55x3mm0.011kg
5V30MA0.15W5-5.5VDCCharge for 3.6V-3.7V Battery53x30x3mm0.005kg
5V60MA0.3W68x36x3mm0.01kg
5V150MA0.75W99x69x3mm0.02kg
5.5V50MA80x35x3mm0.01kg
5.5V60MA0.3W100x28x3mm0.01kg
5.5V100MA0.55W84.5x55.5x3mm0.018kg
5.5V120MA0.66W80x60x3mm0.02kg
6.5V90MA0.6W6-6.5VDC120x70x3mm0.03kg
6V100MA0.6W120x38x3mm0.016kg
6V330MA2W136x110x3mm0.06kg
6V500MA3W145x145x3mm0.07kg
6V580MA3.5W135x165x3mm0.077kg
6V750MA4.5W145x145x3mm0.07kg
8V150MA1.2W8VDCCharge for 6V Battery145x95x3mm0.05kg
12V250MA3W12VDCCharge for 8V Battery145x145x3mm0.07kg
18V190MA3.5W18VDCCharge for 12V Battery165x135x3mm0.082kg
18V200MA4.2W200x130x3mm0.109kg

Application:


Solar garden lighting


Small home lighting system


Solar street lighting


Solar outdoor advertising


For a variety of low-power appliances, such as emergency lights, advertising lights, traffic lights, home


lights, fans, solar water pumps, solar lights and small solar systems and so on.


solar lawn lights, solar wall lights, solar products, solar toys, solar radio, solar flashlight, solar cell phone


charger, small solar water pumps, solar home / office power and portable power systems.


On the use and testing of: products can only be in the sun, the nominal peak power is the midday sun, the


sun early in the morning one night and not the strong sun is not up to the nominal, buyers pay attention to


this point and in the light! inside the room, the solar panels are almost undetectable what value! This is an


ordinary light and the sun's light caused by very different! So be sure to test the under sunny!



How Do Solar Panels Work?


When photons hit a solar cell, they knock electrons loose from their atoms. If conductors are attached to


the positive and negative sides of a cell, it forms an electrical circuit. When electrons flow through such a


circuit, they generate electricity. Multiple cells make up a solar panel, and multiple panels (modules) can be


wired together to form a solar array. The more panels you can deploy, the more energy you can expect to


generate.
